PRODUCT FEATURES

Construction and Materials

• Die-cast aluminum housing and heat-sink for added protection
• Support O/G Hook for mounting
• Lens is made of polycarbonate

Optical System

• Optics available: 120°/100°/60°

Electrical System

• Static and Power Selectable options: 100W / 120W / 150W / 200W / 240W / 310W
• Input Voltage: 120-277VAC
• Efficacy: 150 lm/W ~ 170 lm/W
• Power Factor: >0.9
• CRI: 80CRI Standard / 90CRI Optional
• Operating Temp: -22°F to 136°F (-30°C to 58°C)
• Total Harmonic Distortion: <15%
• Integral Surge Protection: 6KV @ 120-277V and 4KV @ 277-480V

Dimming & Controls Options

• 6ft power cord and 1ft dimming feed standard
• Dimming Capability and Range: Continuous Dimming to 10% or below
• Integral Control Capability: LLLC
• Sensor Types: Daylight Sensing, Occupancy Sensing
• SSL V5 Wired Communication Protocol: 0-10V Analog
• SSL V5 Wireless Communication Protocol: Bluetooth

Certifications and Compliance

• UL Listed for Wet Locations
• DLC Premium Listed – visit designlights.org for more info
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on TM21: L70 ≥ 150,000 / L80 ≥ 120,000 / L90 ≥ 61,000 Hrs

DOWNLOADS

MORE DOWNLOADS

CONTROLS OPTIONS

Go to Controls Page

OPTIONAL FEATURES

• 277-480V Available only on Straight Wattage Models
• Bi-level Microwave Occupancy/Motion Sensor, Bi-level Microwave Occupancy/Motion Sensor with Daylight Harvesting, and PIR Sensor
• Emergency Battery Backup
• O-Hook, U-Bracket, Pendant Mount Adapter, or Metal J-Box for Mounting
• Aluminum Reflector and PC Refractor
• CASAMBI Bluetooth Lighting Control System
• TruBlu Mesh Network Bluetooth Lighting Control System
• Custom Colors as Special Order – Identify RAL Color Code on order
