PRODUCT FEATURES

Construction and Materials

• Cast Aluminum with Epoxy Powder Coat Finish
• Acrylic Lens

Optical System

• 95.8° / 161.2° Light Distribution

Electrical System

• Input Power: 22W / 39W
• Input Voltage: 120-277VAC
• CCT Selectable: 3000K/4000K/5000K
• Efficacy: 111 lm/W max
• Power Factor: >0.9
• CRI: >70 CRI
• Operating Temp: -40°C to +60°C (-40°F to +140°F) Ambient
• Total Harmonic Distortion: <15%
• Integral Surge Protection: L/N-PE: 4kV, L-N: 4kV

Dimming and Controls

• 0-10VDC Continuous Dimming Standard

Certifications and Compliance

• UL Listed for Wet Locations
• Ingress Protection: IP65 for Wet Locations
• RoHS compliant
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions
• Complies with Dark Sky Requirements

Lifetime Based on TM21:

• L70 ≥ 116,000 / L80 ≥ 109,000 / L90 ≥ 61,000 Hrs
