PRODUCT FEATURES

• IP65 Rated – High ingress protection
• 2×4, 2×2, 1×4, two mounting types:
  – Recessed T-Grid ceiling
  – Hard/Drywall ceiling
• Designed for cleanroom applications in ISO 1 rated cleanrooms where ceiling space is limited
• High efficacy LED light source with 80/90+ CRI with tunable white option

SPECIFICATIONS

• LIGHT SOURCE: High output, high CRI LED light source comes with standard options: 19K / 27K / 30K / 35K / 40K / 50K, TW (27K‑65K), RGBA (Red, Green, Blue, Amber).
• Serviceable Tunable White, mid-power LED array provides 2700K through 6500K CCT range with a two-point path. Minimum 82 CRI standard (R9 >20) with optional minimum 90 – CRI (R9 >50).
• MOUNTING: T-Grid & Hard/Drywall ceiling
• Suitable for:
  – Insulation Contact (IC) recessed ceiling installation into 9/16″ and 15/16″ grid and flanged drywall ceilings (5/8″ max). See Ordering Information for selection;
  – 0°C – 40°C ambient temperature environments;
  – Applications requiring USP 797 and USP 800 compliance.
• One piece inset doorframe, secured to housing with aircraft cables
• HOUSING Made of 6063-T5 aluminium construction with gasketed aluminium endcaps. Low-gloss anti-microbial white TGIC polyester powder-coat finish with five-stage pre-treatment.
• Fully Welded Construction: Robust and durable, providing long-lasting structural integrity
• Housing color: White (RAL9003) / Or Custom RAL color
• Concealed Front Fixings: Sleek design with hidden fixings for a clean and professional appearance
• ANTIBACTERIAL Coating: Ensures a hygienic surface, critical for clean room applications
• LENS/DIFFUSER options: Tempered glass (IK08), standard PC, or antibacterial PC lens (IK10)
• Certified Clean room Compatibility: Fraunhofer IPA Certificate for use in ISO Cleanliness Classes 1 to 9, guaranteeing suitability for stringent clean room standards
• IP65 / NSF / ANSI 2 / P442 Rated
• Plenum Rated, RFI Filter Standard, ISO 1
• WALKABLE FIXTURE Tested and rated at 150Kg/330Lbs
• Multiple diffuser options: Tempered glass (IK08), standard PC, or antibacterial PC lens (IK10)
• ANTIBACTERIAL PC LENS thickness: 1.35 MM
• PC LENS thickness: 1.3MM Standard PC diffuser includes toughened glass for areas needing extra chemical protection UGR<22 Low glare lens
• TEMPERED LENS thickness: 2MM
• WARRANTY 10Yr limited.
