PRODUCT FEATURES

• IP65 Rated for high ingress protection
• Multiple diffuser options: Tempered glass (IK08), standard PC, or anti-virus PC (IK03)
• High luminous efficacy: 110 lm/W to 125 lm/W
• Color temperatures: 3000K, 4000K, 5000K, 6500K
• UGR <22 for glare-free lighting
• CRI >80 for excellent color rendering
• Dimming options: Non-dim, DALI, Push-dim, 0/1-10V
• Power range: 26W to 60W depending on model
• Lifespan: >50,000 hours (L80B20 @ 25°C)
• RAL 9003 white finish for a clean, professional appearance
• Easy recessed mounting with a side-arm bracket (clamping range 20–80 mm). No tools needed for the front face; maintenance is fast and simple

Electrical Specifications

• Input Power options:
  1X4FT (40W / 30W / 25W)
  2X2FT (40W / 30W / 25W)
  2X4FT (135W / 90W / 50W / 40W / 30W)
• CCT options:
  CCT Static (19K / 27K / 30K / 35K / 40K / 50K)
  TW (27K – 65K)
  R (Red) / G (Green) / B (Blue) / A (Amber)
• Input Voltage: CC 120-277VAC/347VAC Internal driver
• Output Voltage: 25-42VDC
• Power Factor: >0.9 / THD: ≤20%
• Centralized driver solution (Multiple fixtures powered via one driver option)
• Certifications: Insulation Class II; Fraunhofer IPA Certificate for clean room; compatibility in clean rooms in ISO Cleanliness (Classes 1 to 9)
