PRODUCT FEATURES

Construction & Materials

• Modular design ‑ beamspreads can be easily swapped without tools
• Rigid die cast aluminum housing acting as the heat sink to maximize life
• Powder coated polyester paint finish

Optical System

• Beam angle: 15°, 24°, 36°, 60° options

Electrical System

• Power Selectable:
  4″ (25W/18W/12W) / 6″ (40W/30W.20W) / 8″ (58W/45W/30W)
• CCT Static: 2700K / 3000K / 3500K / 4000K
• Input Voltage: 120‑277VAC
• Efficacy: 90 lms/W to 105 lms/W
• Power Factor: >0.9
• COB LED Chip: >80CRI Standard, >90CRI Optional
• Operating Temp: 0°F to 104°F (‑18°C to 40°C)
• Total Harmonic Distortion: <20%

Dimming & Controls

• 0‑10V Dimming Standard
• 1% Dimming Optional
• TRIAC Dimming Optional

Mounting

• Surface or Pendant mounting

Certifications and Compliance

• UL Listed for Damp Locations
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on TM21: L80 ≥ 50,000 Hrs
