PRODUCT FEATURES

• Construction and Materials:
  • Patent designed to be Curved Fin Shape, maximizing the best heat transmission
  • Aluminum alloy (ADC12)
  • Tempered Glass Lens (8mm) shock and vibration resistant, clear with >90% light transmission
  • Threaded Hole Opening: M25X1.5 (Standard)
  • U-Bracket Mount Included
• Adjustable Light Distribution: 15°, 60°, 90°, 108°, 120°
• Electrical System:
  • Input Power: 40W / 100W / 185W
  • Input Voltage: 100-277VAC 50/60Hz
  • Driver Qty: (1) Meanwell HLG Series Driver
  • CCT: 3000K / 4000K / 5000K
  • Efficacy: 130 lm/W on average
  • Power Factor: >0.97
  • CRI: >70
  • Operating Temp: -22°F to 140°F (-30°C to +60°C)
  • Total Harmonic Distortion: <10%
  • Integral Surge Protection: 4KV/6KV Surge Protection Power Supply
• Certifications and Compliance:
  • NEC/CEC: Class I, Division 2, Groups A, B, C and D
  • T-Class: T6 for 40W and 100W Models, T5 for 200W model
  • UL Listed for Damp and wet locations
  • Ingress Protection: IP67, high protection grade for waterproof and dust-proof
  • RoHS compliant
  • Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions
• Lifetime Based on TM21: L70 ≥ 181,000 / L80 ≥ 132,000 / L90 ≥ 101,000 Hrs
