PRODUCT FEATURES

Construction and Materials

• Die-cast aluminum housing
• Powder coat corrosion resistant finish, with High Transmittance Polycarbonate Lens

Optical System

• 100° Light Distribution Standard
• 60°x110° Aisle Lighting Optic Option
• UGR: 22.9

Electrical System

• Power Selectable:
  [130W/105W/90W],
  [155W/130W/115W],
  [210W/180W/155W],
  [310W/270W/240W],
  [420W/360W/310W]
• Selectable CCT: 4000K/5000K
• Input Voltage: 120-277VAC Standard or 277-480VAC Option, 50/60Hz
• Efficacy: up to 170 lm/W
• CRI: >80 Standard
• Operating Temp:-40°F to 122°F (-40°C to 50°C)
• Integral Surge Protection: L/N-PE: 10kV, L-N: 6kV surge (120-277V/277-480V)

Dimming and Controls

• 0-10V Dimming Standard

Certifications and Compliance

• UL 924 Listed
• RoHS compliant
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

OPTIONAL FEATURES

• Remote Controlled Plug and Play Microwave Bi-Level Motion Sensor
• Remote Controlled PIR Motion Sensor
• Bluetooth® Indoor Controls System managed with the Jademar BT Local App
• Emergency Battery Backup: 8W, 15W or 20W Options
• Mounting Options: Pendant or Surface Mount Kit
• Wire guard protection for all sizes
