PRODUCT FEATURES

Construction and Materials

• Aluminum Alloy Housing and Polycarbonate Diffused Lens
• Chain/Hook Pendant Mount Kit

Optical System

• 105° Light Distribution

Electrical System

• Input Power Selectable:
  135W / 110W / 100W
  200W / 185W / 155W
  270W / 230W / 200W
  400W / 340W / 270W
• Selectable CCT: 4000K/5000K
• Input Voltage: 120-277VAC or 277-480VAC
• Efficacy: 136 lm/W on average
• Power Factor: >0.98
• CRI: >80 Standard
• Operating Temp:-22°F to 113°F (-30°C to 45°C)
• Total Harmonic Distortion: 10%
• Integral Surge Protection: L/N-PE: 2kV, L-N: 2kV

Controls Features

• Integral Controls Capable
• Dimming Capability and Range: Continuous Dimming to 10% or below
• Integral Control Capability: LLLC, Energy Monitoring, High End Trim
• Sensor Type: Occupancy Sensing
• SSL V5 Wired Communication Protocol: 0-10V Analog and Bluetooth

Certifications and Compliance

• UL 924 Listed
• BAA, RoHS compliant
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on TM21: L70 ≥ 181,000 Hrs / L80 ≥ 132,000 Hrs / L90 ≥ 101,000 Hrs

OPTIONAL FEATURES

• Remote Controlled Plug and Play Microwave Bi-Level Motion Sensor
• Remote Controlled PIR Motion Sensor
• Bluetooth® Indoor Controls System managed with the Jademar BT Local App
• Emergency Battery Backup: 8W, 15W or 20W Options
• Mounting Options: J-Box or Surface Mount Kit
• Wire guard protection for all sizes
