PRODUCT FEATURES

• Special:
  • Lumileds Chip, high CRI
  • Output constant current level can be adjusted through output cable with APP
  • No UV or IR in the beam
  • Easy to install and operate
  • Energy saving, long lifespan
  • Light is soft and uniform, safe to eyes
  • Instant start, NO humming
  • Green and eco-friendly without mercury
• Construction:
  • Die-cast aluminum
  • Finish: Black / White / Customized
• Optical System:
  • Beam Angle (50%): 90 Degrees
  • Color Consistency: <7 Steps (or <7 SDCM)
  • UGR: <28 (X=4H, Y=8H; S/H=1; Reflectances: 70%/50%/20%)
  • Diffuser Type: PC Lens
• Electrical System:
  • Input Power: 100W
  • Input Voltage: CC 120-277VAC Internal driver
  • Efficacy: 17 lm/W ~ 147 lm/W
  • Power Factor: ≥0.9
  • CRI: 90+
  • Operating Temp: -40°F to 122°F (-40°C to 50°C)
  • Storage Temp: -40°F to 176°F (-40°C to 80°C)
  • Total Harmonic Distortion: ≤20%
  • Driver Surge Protection: L/N-PE: 6kV, L-N: 6kV

DOWNLOADS

MORE DOWNLOADS

CONTROLS OPTIONS

Go to Controls Page

• DMX Driver
• DALI Driver
• Built-In Bluetooth app controller
• 0-10V Dimming

CERTIFICATIONS & COMPLIANCE

• UL & cUL Listed
• IP65
• NSF Rated
