PRODUCT FEATURES

Construction and Materials

• Polycarbonate Lens and Cast Aluminum Alloy Housing

Optic/Lens

• 156° Light Distribution Static
• UGR Rating: 18

Electrical System

• Power: Static: 45W / 70W / 90W / Selectable: 70W (70W/56W/42W/28W)
• Input Voltage: 120-277VAC
• Efficacy: 140 lm/W
• Power Factor: 0.95
• CRI: >70
• Operating Temp: -22°F to 113°F (-30°C to 45°C)
• With Internal EM Pack Operating Temp: -22°F to 113°F (-30°C to 45°C)
• Total Harmonic Distortion: <15%
• Integral Surge Protection: 6kV Surge Protection Standard

Dimming

• 0-10V Continuous Dimming Standard

Certifications and Compliance

• UL / DLC Listed (see page 2 of Spec sheet for listed models)
• Ingress Protection: Wet Locations
• RoHS compliant
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on TM21: L70 > 143,000 / L80 > 122,000 / L90 > 73,000 Hrs
