PRODUCT FEATURES

Construction and Materials

• Aluminum Alloy with White Powder Coat Finish and Frosted Acrylic Lens

Optical System

• 112° PC Optics Standard

Electrical System

• Input Power: 2′ (25W/20W/15W) / 4′ (40W/30W/25W) / 8′ (65W/60W/55W) /
  8′ (91W/75W/65W)
• Input Voltage: 120-277VAC
• CCT Selectable: 3500K/4000K/5000K
• Efficacy: >130 lm/W
• Power Factor: >0.90
• CRI: >80
• Operating Temp:-40°F to 127°F (-40°C to 53°C)
• Total Harmonic Distortion: >14% on average
• Integral Surge Protection: L/N-PE: 2kV, L-N: 2kV

Dimming and Controls

• 12VDC Auxiliary Dimming and Integral Controls
• Dimming Capability and Range: Continuous Dimming to 10% or below
• Integral Control Capability: Energy Monitoring, High End Trim, LLLC
• Sensor Type: Occupancy Sensing

Certifications and Compliance

• UL, DLC Premium, FCC Listed
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on TM21: L70 ≥ 180,000 Hrs / L80 ≥ 130,000 Hrs / L90 ≥ 100,000 Hrs

OPTIONAL FEATURES

• Bi-Level Microwave Occupancy/Motion Sensor with Daylight Harvesting
• Bi-level microwave Stand-Alone Sensor with free Bluetooth smart device App with programmable remote
• Emergency Battery Backup 8W or 15W option
• 3-Wire or 5-Wire Metal/Flex Conduit and Linkable Cable for Quick Connect
• Additional Power Cord Length
• NEMA Plug Options
• Suspension Mounting Kit
• Strip Light Connector and Wire Guard options for 2FT / 4FT / 8FT

DOWNLOADS

MORE DOWNLOADS

CONTROLS OPTIONS

Go to Controls Page

APPLICATIONS

• Commercial: Shopping Malls and Storage Facilities
• Industrial: Lower Ceiling Warehouses and Manufacturing Plants
• Residential: Garages, Building Stairwells and Hallways
