PRODUCT FEATURES

Construction and Materials

• Rugged die-cast aluminum body that uses heatsink and flow-through venting to provide optimal thermal management that both enhances LED performance and extends component life
• The light housing is sealed against moisture and environmental contaminants
• The 3G vibration rated compact design minimizes wind load requirements
• Low EPA for pole optimization

Optical System

• Light engines are available in 4000K or 5000K, and CRI70 configurations
• Two distributions Tennis Court TYPE III and Sports Field optional

Electrical System

• Power Selectable: 400W / 320W / 240W; 600W / 480W / 360W
• CCT Options: 4000K / 5000K
• Input Voltage: 120-277V / 120-347V / 277-480V (50/60Hz)
• Power Factor: ≥0.9
• CRI: 70 Standard / 80 & 90 Optional
• Ambient Temp: -40°C to 50°C (-40°F to 122°F)
• Total Harmonic Distortion: ≤20%
• Integral Surge Protection: L/N-PE: 20kV, L-N: 20kV

Mounting

• Slip Fitter Mount
• Square and Round Pole Mount Arm
• Trunnion Mount
• Yoke Mount
• Adjustable Square and Round Pole Mount Arm

Dimming and Controls

• 0-10V Dimming Standard
• Network Lighting Control Options: Synapse, Casambi, Bubblynet & Silvair

Certifications and Compliance

• Wet Location
• 3G Vibration rated
