Network Lighting Control System
Based on Bluetooth Low Energy wireless technology, the Casambi-powered Smart Sensor Control Platform provides a self-organizing, self-healing mesh network capable of controlling lighting fixtures throughout a floor or building from any location. With onboard intelligence in every device, and virtually effortless tweaks to sequences of operations or additions of new devices when building needs evolve, the Casambi-powered control network affords fingertip control now and flexibility for the future.
You may find CASAMBI Sales Sheet and Application Docs below
CASAMBI SYSTEM OVERVIEW
CASAMBI Sales Sheet and Application Docs
CASAMBI RGB/RGBW Solution Tutorials
CBU-PWM4 Overview Video
Tutorial – CBU-PWM4 RGB Profiles
AVAILABLE PRODUCTS TABLE
Product Name | Product Description |
Casambi Fixture Controller, Side Mount, 12VDC, comes with Low voltage Connector, IP65 Rated |
|
Casambi Mesh Fixture Controller, 12-24VDC, Single Channel 0-10 Volt Dimming |
|
Casambi Mesh Fixture Controller, 12-24VDC, Single Channel 0-10 Volt Dimming, With External Antenna Connect |
|
Outdoor rated 5DP external Antenna for PSC-WCM-50/EXA-BLE-CB |
|
Casambi Mesh Fixture Controller, 12-24VDC, Single Channel 0-10 Volt Dimming, With Sensor Input |
|
Casambi Mesh Dual Channel Fixture Controller for Dim-to-Off driver, 12-24VDC |
|
Casambi Mesh Dual Channel Fixture Controller, 12-24VDC, with sensor input |
|
Casambi Mesh Fixture Controller, 120-277 Volt with dimming, 10A Relay |
|
Casambi Mesh Fixture Controller, 12-24VDC, Single Channel 0-10 Volt Dimming, Z10 |
|
Casambi Mesh Fixture Controller, 12-24VDC, Single Channel 0-10 Volt Dimming, Z10 with photocell |
|
Casambi Mesh Fixture Controller, Single Channel DALI Zhaga |
|
Casambi SIG Mesh Fixture Controller, 12-24VDC, Single Channel 0-10 Volt Dimming, Z10, with antenna built-in |
|
Casambi 4 Channel CBU-PWM4-4 PWM Dimmer/Fixture Controller for RGBW/RGB or static CCT 4 Strips |
|
DMXCAS DMX-to-Casambi 4-Channel DMX Dimmer |
|
Bluetooth controllable DALI controller, 12-24VDC, 30ma input |
|
Line Voltage Range Extender – Range Extender, Max Bluetooth Range up to 800 ft umbrella in diameter (240 m) |
|
Time keeper, Line Voltage Input 120 VAC, Back-up Battery approximately 24 hours – Need per site/location – Not needed if design with gateway |
Product Name | Product Description |
Mesh Room Controller, 120-277 Volt with dimming, 10A Relay |
|
Mesh Room Controller, 120-277 Volt with dimming, 12 volt Aux, Sensor input, 20A Relay |
|
Integrates Wired DALI Drivers into Casambi up to 64 drivers |
Product Name | Product Description |
Power pack 120-277VAC Input – 12-24VDC Output with 20A relay |
|
Power pack 120-277VAC Input – 12-24VDC Output with 2A relay, 100mA |
Product Name | Product Description |
HIGH BAY | |
Casambi Mesh PIR Highbay/Lowbay 0-10V Dimming Sensor, 120/277 Volt |
|
Casambi Mesh PIR Highbay/Lowbay 0-10V Dimming Sensor, 12-24VDC |
|
Casambi Mesh PIR Highbay/Lowbay 0-10V Dimming Sensor, 12-24VDC, side/bottom mount |
|
Casambi Mesh PIR Highbay/Lowbay 0-10V Dimming Sensor, 12-24VDC, Z-10 |
|
Casambi Mesh Microwave 0-10V Dimming Sensor, 12-24VDC |
|
Casambi Mesh Microwave 0-10V Dimming Sensor, 12-24VDC, Z-10 |
|
LOW BAY | |
Casambi Mesh Microwave 0-10V Dimming Sensor, 12-24VDC, Fixture mount |
|
Casambi Mesh PIR & Day Light Sensor 0-10V Dimming Sensor, 12-24VDC, Plug & Play Fixture mount |
|
Casambi Mesh PIR 0-10V Dimming Sensor, 12-24VDC, Remote Head |
|
Casambi Mesh PIR and Daylight 0-10V Dimming Sensor Combo, 12-24VDC, Remote Head |
|
Casambi Mesh Ultrasonic 0-10V Dimming Sensor, 12-24VDC |
|
Casambi Mesh Microwave 0-10V Dimming Sensor, 12-24VDC, IP65 Rated Side/Bottom Mount |
|
Casambi Mesh Microwave 0-10V Dimming Sensor, 12-24VDC, Remote Head |
Product Name | Product Description |
Casambi Ceiling Mount Dual Technology Wireless Sensor, 12-24VDC |
|
12-24VDC Ceiling Mount Wireless PIR Motion Sensor, use CASAMBI app for control |
|
12-24V, 0-10V DIMMING, MAX MOUNTING HEIGHT 12FT, IP20, CEILING SENSOR, USE CASAMBI APP TO CONTROL |
|
12-24V, 0-10V DIMMING, MOUNTING HEIGHT MAX 40FT, IP65, USE CASAMBI APP TO CONTROL |
Product Name | Product Description |
Batteryless EnOcean Switch, Single Rocker: On/Off & Dimming |
|
Batteryless EnOcean Switch, Double Rockers: On/Off and Dimming / Tunable White |
|
Casambi Mesh Dimming Wall Sensor Switch, 120-277V: On/Off & Dimming |
|
Casambi Mesh Dimming Wall Switch, 120-277V: On/Off & Dimming |
|
Casambi Mesh Dimming 4 Buttons Wall Station, 120-277V: On/Off and Dimming / Tunable White |
|
120VAC WIRELESS 2-BUTTON DIMMER WALL SWITCH, BLUETOOTH MESH |
|
Dual Technology Occupancy/Vacancy Wall Switch Sensor: On/Off & Dimming |
|
Battery or Line Voltage Powered 4 to 8 Buttons Casambi Wall Switch: On/Off and Dimming / Tunable White |
|
Battery Powered Casambi Wall Switch: On/Off and Dimming / Tunable White |
|
Digital Touch Screen Control Panel: On/Off, Dimming, RGB/GBW Color picker |
|
Wall Switch Custom Text Engraving Form |
Product Name | Product Description |
Rigado’s Cascade-500 IoT Gateway – powerful and cost-effective solution for large-scale low-power wireless deployments |
|
Wireless Bluetooth Mesh BACnet Gateway – Supported BACnet Interoperability Building Blocks (BIBBs) |
|
Casambi Solution – UL924 V.1 (Mar 2025) |
