Product Features

Construction and Materials

• Extruded aluminum housing
• Ultra thin profile: only 0.59″ (15mm) thickness, available in 4′, 8′ length

Optical System

• Light Distribution: 120°

Electrical Parameters

• Power: 40W/30W/20W (4FT Model) / 80W (8FT Model)
• Input Voltage: CC 120-277VAC Internal driver
• Efficacy: up to 42 lm/W to 106 lm/W
• Power Factor: >0.9
• CRI: >80
• Operating Temp: -40°F to 113°F (-40°C to 45°C)
• Total Harmonic Distortion: <15%
• Integral Surge Protection: 6kV Surge Protection Standard

Dimming and Controls

• 0-10V Dimming Standard

Certifications and Compliance

• UL Listed
• NSF Rated
• Ingress Protection: IP66 for Wet Locations
• RoHS Compliant
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on IES LM-80:

• L70 ≥ 150,000 / L80 ≥ 120,000 / L90 ≥ 61,000 Hrs
