PRODUCT FEATURES

Construction and Materials

• Extruded aluminum housing
• Powder coat white finish provides long term performance and superior aesthetic

Optical System

• 131.7° & 133.4° Beam Angle
• Transparent Optics

Electrical System

• Power Selectable: 40W (40W/30W/20W) and 50W (50W/40W/30W)
• CCT Selectable: 4000K / 3500K / 3000K
• Input Voltage: 120-277VAC Standard / 120-347VAC
• Average Efficacy: 111 lm/W
• Power Factor: >0.9
• CRI: >80 / >90
• Operating Temp: -20°C to 40°C (-4°F to 104°F)
• Total Harmonic Distortion: <20%
• Integral Surge Protection: 6KV

Controls Features

• 1-10V Continuous Dimming Standard

Certifications and Compliance

• UL Listed for Damp Locations
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Mounting Options

• Recessed in T-bar Grid Ceiling Mount

Lifetime Based on TM21: L70 ≥ 173,000 Hrs / L80 ≥ 133,000 Hrs / L90 ≥ 111,000 Hrs

DOWNLOADS

MORE DOWNLOADS

OPTIONAL FEATURES

• Bi-Level Microwave Occupancy/Motion Sensor
• Wireless Bluetooth Network Lighting Controls Systems
• 8W & 15W Emergency Battery Backup
