PRODUCT FEATURES

Construction and Materials

• Extruded aluminum housing with powder coat white finish provides long term performance and superior aesthetic

Optical System

• 110° Beam Angle

Electrical System

• Power Selectable: 35W (35W/30W/25W) and 50W (50W/40W/30W)
• CCT Selectable: 3500K / 4000K / 5000K
• Input Voltage: 120-277VAC
• Efficacy: 130 lm/W
• Power Factor: >0.9
• CRI: >80
• Operating Temp: -4°F to 104°F (-20°C to 40°C)
• Total Harmonic Distortion: <20%

Controls Features

• Dimming Capability and Range: Continuous Dimming to 10% or below
• Optional Sensors: Occupancy Sensing

Certifications and Compliance

• UL Listed for Damp Locations
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Mounting Options

• Recessed in T-bar Grid Ceiling Mount

Lifetime Based on TM21: L70 ≥ 183,000 Hrs / L80 ≥ 143,000 Hrs / L90 ≥ 121,000 Hrs

DOWNLOADS

MORE DOWNLOADS

OPTIONAL FEATURES

• Bi-Level Microwave Occupancy/Motion Sensor
• Bluetooth Indoor Controls Systems operated by our own smart app Jademar BT Local
• 6W, 8W, 15W, 20W & 25W Emergency Battery Backup
• 3 or 5-Wire – 6ft (3/8″ Metal conduit/flex conduit), 1/2″ quick connectors, #18 solid (600V) – (black, white, green, violet, grey)
