STANDARD FEATURES

Construction and Materials

• 3G Vibration tested; Rugged all weather housing
• Machine Spun Aluminum Al1070, Epoxy Powder Coat Finish
• Polycarbonate Lens
• Equipped with a 6FT Power Cord

Optical System

• Optic/Distribution Types & Options: 15°/18°/20°/30°/40°/60°/80°/120°

Electrical System

• Wattage: 500W / 750W / 1200W
• CCT: RGB / RGBW / RGBA
• Input Voltage: 120-277VAC / 277-480VAC
• Power Factor: >0.9
• Operating Temp: -40°F to 113°F (-40°C to 45°C)
• Total Harmonic Distortion: <20%
• Integral Surge Protection: Line to line 6kV in the driver, line to ground 10kV,
  IEC 61000-4-50

Dimming & Controls

• DMX Driver for RGB/RGBA/RGBW Entertainment Features
• 12VDC Auxiliary output is a standard feature cross the board with all driver options

Certifications and Compliance

• UL Listed for Wet Locations
• Ingress Protection: IP66 for Wet Locations
• HD4K Filming Rated
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Lifetime Based on TM21: L70 ≥ 187,000 / L80 ≥ 162,000 / L90 ≥ 100,000 Hrs

DOWNLOADS

MODE DOWNLOADS

OPTIONAL FEATURES

• High Voltage Option 277-480VAC
• 20kV Surge Protection Device
• Slipfitter Mount
• Mounting Laser Pointer
