JSLP-HE SERIES
PREMIUM LED SPORTS LIGHTING
Product Features
Construction and Materials
- 3G Vibration tested; Rugged all weather housing
- Machine Spun Aluminum Al1070, Epoxy Powder Coat Finish
- Polycarbonate Lens
- Equipped with a 6FT Power Cord (12FT Power Cord Optional)
Optical System
- Optic/Distribution Types & Options: 15°/18°/20°/30°/40°/60°/80°/120°
- Light Distribution: NEMA 4 Standard / NEMA:5 / NEMA:6 / NEMA:7 Optional
Electrical System
- Wattage: 400W / 500W / 600W / 750W / 1000W / 1200W
- CCT: 4000K / 5000K
- Input Voltage: 120-277VAC / 277-480VAC
- Efficacy: 130 lm/W to 160 lm/W
- Power Factor: >0.9
- CRI: ≥70 Standard / 80 & 90 Optional
- Operating Temp: -40°F to 113°F (-40°C to 45°C)
- Total Harmonic Distortion: <20%
- Integral Surge Protection: Line to line 6kV in the driver, line to ground 10kV,
IEC 61000-4-50
Dimming & Controls
- Built with fast dimming driver technology compatible with Synapse Dynamic Behavior feature
- DALI2 or DMX Driver Dimming Driver
- 12VDC Auxiliary output Mounting
- Adjustable U-Bracket or Slipfitter Mount
Mounting
- Adjustable U-Bracket or Slipfitter Mount
Certifications and Compliance
- UL Listed for Wet Locations
- Ingress Protection: IP65 for Wet Locations
- HD4K Filming Rated
- Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions
Lifetime Based on TM21
- L70 ≥ 187,000 / L80 ≥ 162,000 / L90 ≥ 100,000 Hrs
