Product Features

Construction and Materials

• Aluminum Frame in powder coated matte finish and steel die-formed back enclosure and PMMA lenses over LEDs /PS diffuser, SDCM <5 / UGR <22

Optical System

• 119° Beam Angle

Electrical System

• Power Selectable: 28W (28W/20W/17W/14) and 45W (45W/38W/34W)
• CCT Selectable: 3000K, 3500K, 4000K, 5000K, 6500K
• Tunable White (2700K-6000K) optional
• Input Voltage: CC 120-277VAC Internal driver
• Efficacy: 125 lm/W to 144 lm/W
• Power Factor: >0.9
• CRI: >80 Standard / 90 Optional
• Operating Temp: -4°F to 104°F (-20°C to 40°C)
• Total Harmonic Distortion: <15%
• Integral Surge Protection: 6kV

Controls Features

• Dimming Capability and Range: Continuous Dimming to 10% or below
• Integral Control Capability: LLLC, Energy Monitoring, and High End Trim
• Sensor Types: Sensor Receptacle, Daylight Sensing, Occupancy Sensing
• SSL V5 Wireless Communication Protocol: Bluetooth

Certifications and Compliance

• DLC Premium, UL Listed for Damp Locations
• RoHS Compliant
• Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions

Mounting Options

• Recessed in T-bar Grid Ceiling Mount
• Surface Mount Kit options

Lifetime Based on TM21: L70 ≥ 183,000 Hrs / L80 ≥ 143,000 Hrs / L90 ≥ 121,000 Hrs

DOWNLOADS

MORE DOWNLOADS

OPTIONAL FEATURES

• Bi-Level Microwave Occupancy/Motion Sensor
• Bluetooth Indoor Controls Systems operated by our own smart app Jademar BT Local
• 8W or 15W Emergency Battery Backup
• 3 or 5-Wire – 6ft (3/8″ Metal conduit/flex conduit), 1/2″ quick connectors, #18 solid (600V) – (black, white, green, violet, grey)
